SDC (2025) Tri Axle Cheesewedge Trailer

MACS TRAILERS -  Cheesewedge style ramps – Hydraulic ramps – Air suspension – BPW axles – Lashing points in the floor and in the side raves – 57mm eye – Rear drop down steady legs – LED rear lights – IN STOCK WITH RANGE OF COLOURS. Axles and Suspension: 3 BPW 9 Ton Axles (Airlite) fitted with Low Maintenance Hubs and Front Lift Axle. Lift axle to be hangar mounted Knorr Bremse G2 EBS 2s2m Braking with Roll Stability System c/w QRV Automatic slack adjusters. Spring Brakes fitted The Brake system is a 2 line operation with C type couplings. An Auto Reset Raise and Lower Valve is Fitted to Suspension N/S Rear Knorr Bremse Type Pull Valves Fitted N/S. Front lift axle to drop when load is greater than 14000kgs on bogie Chassis: Couplings are Plate Mounted on Front Face Plate. VBG Box Section Extending Towing Arm fitted c/w VBG 50mm Towing Eye Extends in 2 x 300mm increments Landing leg fitted to extendable towing arm 3 Pair of Chassis Lashing Rings Fitted - Painted Yellow (Not for Ferry use) There are Heavy Duty 16mm Rope Hooks fitted to every crossmember. Cross members are IPEA80 Spaced at 450mm Pitch 150 x 75 Heavy Duty Channel side rave fitted with Mouth Turned Outwards. 28 mm Keruing Floor Fitted Between the Beams C/W chequer plate over wheels (painted to match chassis) 8 Pair of Deck Lashing Rings Fitted Swing D rings in chime 2 pairs of 50x50 sockets fitted fitted to front and rear only, to suit 4 off 40 x 40 fall arrest posts with straps Landing Legs: 1 off Low Maintenance JOST Modul, Geared Landing Leg with Flat Foot. Fitted to towing arm Landing leg handle fitted U.K. nearside. Rear Support Legs fitted Electrics: ISO Regulation electrics fitted. Rear Lamps are Single Rubbolite M900 LED Sidelights are Rubbolite 890 - All Lamps Flashing 2 off Stalk Outline Marker Lights are Rubbolite 841 LED Rear marker lights are Rubbolite TL34 LED Air & Electric Suzie Leads Supplied with Trailer. Wheels: 12 Goodyear 215/75 x R17.5 tyres fitted c/w inner valve extensions - KMAX pattern Wheels are 6.5 x 17.5 steel. 6 Off Bolt On Full Length Thermo Plastic Mudwing 6 Off Mudflaps Fitted SDC Logo KMAX: FUEL C: GRIP B: DB 67 Chassis Options: 1 off Steel Toolbox fitted. Stainless steel - fitted O/S. Standard 60Lt steel Airtanks fitted. Conspicuity markings side (white- solid line type) and rear (red) (UK) SDC Chassis Plate Fitted. Ministry 'C' Number Applied for & stamped to chassis plate Fit SDC Badges VTG 6A holder model no. TTC 20067 fitted to beam forward of landing legs N/S & MOT disc holder fitted Sideguards: Aluminium Sideguards c/w Galvanised Folding Mounting Brackets fitted 2 off Side Guard Down Stays Only Fitted
